8 * 8 WS2812B LED Matrix
Yam Khoom Muag:
P/N | LED Qty / pcs | Qhov Coob (mm) | Pixel | VCC | Lub Zog | IC | Lumen ib pcs | IP |
MDR-0808WS2812 | 5050 RGB 64leds | L80*W80 | 64 | DC5V | 12.8W / pcs | WS2811 | R:25600 G:44800 B:12160 | IP20 |
Nta:
1. WS2812B yeem LED yooj yim-8x8 pixels
2. Nws' s yooj yim heev rau ntxiv cov tsiaj ntawv thaum txhua tus tswj tus kheej.
3. Tus ntawd yog 64 tus kheej ib qho chaw LED nyob ntawm 80mm x 80mm hloov tau vaj huam sib luag.
4. Koj tuaj yeem teeb tsa cov duab txav
5. Cov vaj huam sib luag no xav tau 5V hluav taws xob qis rau lub zog uas yuav tsum muaj peev xwm los ua kom muaj txiaj ntsig zoo ntawm qhov tam sim no - txog 4A hauv feem ntau siv (3.8A yuav tsum tau wen koj teeb txhua LED nyob rau hauv cov xim dawb).
6. Muaj ob qhov txuas 3-pin JST SM txuas thiab ob pcs liab qab lub zog hluav taws xob
7. Liab: DC5V +, Daj: COM-, Ntsuab: DAT, thiab Daj GND.
8. Thaum tag nrho cov vaj huam sib luag teeb li xim dawb, tag nrho cov PCB tau txais kub heev txawm tias yog siv 1 ooj Copper.
9. Koj yuav tsum tau muab fais fab rau txhua lub vaj huam sib luag thaum koj txuas ntau lub hnab
10. Nco tseg: thov them sai sai rau matrix thaum koj khoov vaj huam sib luag hloov tau.
Daim ntawv thov:
1. DIY hluav taws xob ntau lawm.
2. Kev Tshaj Tawm.
3. Cov zaub.
4.Qhov muag
