Lub npe ： Qhov ua haujlwm lub sijhawm coj tus maub los
Qauv ： TC420
Kev nthuav qhia
Ntawm no yog lub tshuab computer sab saud hauv qhov programmable lub sijhawm tswj hwm kom ua rau cov teeb meem hloov tawm lub sijhawm, cov qhua tuaj yeem hloov kho cov sijhawm uas lawv xav tau los ntawm PC sab saud. Tom qab ntawd dhau ntawm USB chaw nres nkoj los rub cov sijhawm yuav tsum tau rau cov maub los.Qhov PC sab saud ntxiv rau kev ua haujlwm ntawm kho daim ntawv teem sijhawm, nws tseem tuaj yeem yog lub sijhawm teeb tsa rau cov maub los vim yog synchronous moos ua haujlwm ntawm lub sab sauv .Yog tus neeg siv xav pom cov sijhawm ua haujlwm hom tom qab hloov kho, lawv tuaj yeem siv ceev tseb muaj nuj nqi ntawm sab sauv. Vim tias tsis muaj qhov kev rho tawm ntawm tus tswv tsev sab saud, yog li hom npe npe tso saib chaw yuav nkag mus rau hauv tsuav koj ua kev rho tawm .Tus maub los no tuaj yeem tswj cov load ntawm cov nyhuv hloov tsis pub dhau tsib raws .Thiab nws tuaj yeem siv rau hauv caij nyoog ntawm cov nroj tsuag teeb, lub thawv teeb pom kev tshaj tawm, theem, kev kho kom zoo nkauj hauv tsev, thiab lwm yam.
Kev tsis
Ua haujlwm kub: -20-60 ℃
Muab cov roj hluav taws xob: DC12V
Kev siv fais fab zoo li qub:<>
Weight Lub cev hnyav: 200g
Cov khoom hnyav: 300g
Ension Sab nraud qhov loj me: 120MM * 69MM * 24MM
● Ntim loj: 169MM * 135MM * 53MM
Tawm Khoom: 5 channel
Output Tshaj tawm ntau tshaj plaws tam sim no: 20A
Cov lus qhia muaj nuj nqi
Muaj ob hom qauv xws li lub zog txuag hom thiab teeb tsa hom nyob hauv tus tswj hwm no, thiab tseem muaj plaub nyees khawm xws li" Ntawv qhia" ;," Nkag" ;," +" ;," -" hauv nws.
1. Lub zog txuag hom
Thaum tus maub los nyob rau hauv qhov xwm txheej teeb tsa tsis muaj ib qho tseem ceeb nias hauv 30 vib nas this, qhov screen tom qab lub teeb yuav raug kaw, thiab yog tias tsis pub dhau 30 vib nas this tseem tsis muaj cov xovxwm tseem ceeb, tus tswj yuav mus rau hauv lub zog txuag hom.
Thaum tus maub los nyob hauv lub zog txuag hom, thawj kab kab ntawm qhov screen qhia tau hais tias hnub tim thiab hom tam sim no; kab thib ob qhia txog lub sijhawm tam sim no.
Hom kev txuag hluav taws xob yog li hauv daim duab 1:
0 | 3 | - | 0 | 7 | - | 2 | 2 | M | o | d | e | 1 | |
0 | 0 | : | 0 | 0 | : | 0 | 0 |
Daim duab 1
2. Teeb tsa tus txheej txheem
Nias" Ntawv qhia" khawm nyob rau hauv cov ntawv qhia zaub mov tseem ceeb, nws yuav nkag mus rau hauv lub sijhawm saib interface.
Thawj kab ntawm lub sij hawm tso saib interface qhia lub sijhawm tam sim no lossis hnub tim thiab hom, nws yuav
cia li hloov txhua ob lub vib nas this.
Qhov thib ob kab qhia tau tias" [Ntawv qhia zaub mov]" ;, nias" Nkag mus" khawm kom nkag tau rau lub ntsiab zaub mov interface.
Lub sij hawm zaub interface yog li hauv daim duab 2:
0 | 3 | - | 0 | 7 | - | 2 | 2 | M | o | d | e | 1 | |
【 | M | e | n | u | 】 |
Daim duab 2
Thaum nias" Nkag" khawm nyob rau hauv lub sijhawm tso saib interface, lossis" Ntawv qhia" khawm nyob rau hauv submenu ntawm lub Main Menu, nws yuav nkag mus rau hauv Main Menu.
Thawj kab qhia qhov chaw" [Ntawv qhia zaub mov]" hauv cov ntawv qhia zaub mov tseem ceeb ntawm lub zaub.
Qhov thib ob kab ntawm cov zaub qhia tau" 1. Hom" ;," 2. Teeb tsa" lossis" 3, Khiav", uas koj tuaj yeem hloov txhua
hom los ntawm kev nias tus lej" +" thiab" -" Cov.
Nias" Nkag" khawm, nws yuav nkag mus rau qhov raug teev hom; thiab nias" Ntawv qhia" khawm rau
rov qab los rau lub sijhawm tso saib interface.
Daim ntawv qhia zaub mov tseem ceeb yog qhia hauv daim duab 3:
【 | M | e | n | u | 】 | |||||
1 | . | M | o | d | e |
Daim duab 3
Xaiv" 1. Hom" hauv cov ntawv qhia zaub mov tseem ceeb thiab nias" Nkag mus rau" khawm kom mus rau hauv hom xaiv xaiv xaiv.
Thawj kab ntawm cov zaub qhia tau hais tias qhov chaw ntawm" 【Hom】" nyob rau hauv hom xaiv raws li txoj cai.
Qhov kab thib ob qhia tau tias lub npe ntawm hom xaiv xws li:" Mode11" Cov.
Nias" +" lossis" -" yuam sij xaiv hom, thiab txuag tau xaiv xaiv hom; Nias" Ntawv qhia" khawm rov qab rau cov zaub mov tseem ceeb.
Cov kev xaiv hom ntawm cov zaub yog li hauv daim duab 4:
【 | M | o | d | e | 】 | |||||
M | o | d | e | 1 | 1 |
Daim duab 4
Xaiv" 2. Teeb tsa" hauv cov ntawv qhia zaub mov tseem ceeb thiab nias" Nkag mus rau" khawm mus rau hauv Daim Ntawv Qhia Teev;
Thawj kab ntawm lub vijtsam qhia tau qhov chaw nyob ntawm" up Teeb】" nyob rau hauv qhov chaw qhia zaub mov raws li txoj cai.
Qhov thib ob kab ntawm cov zaub qhia tau" 1. Sijhawm" thiab" 2. Hnub" lossis" 3. Suab", koj tuaj yeem xaiv teeb tsa
kwv los ntawm qhov tseem ceeb" +" lossis" -" Cov.
Nias" Nkag" khawm kom nkag mus rau qhov chaw cuam tshuam, thiab nyem" Ntawv qhia" khawm rov qab rau Cov Ntawv qhia zaub mov tseem ceeb.
Cov ntawv qhia zaub mov teeb yog li muaj nyob hauv daim duab 5:
【 | S | e | t | u | p | 】 | |||||
1 | . | T | i | m | e |
Daim duab 5
I. Hauv cov xwm txheej ntawm kev teeb tsa cov ntawv qhia zaub mov, xaiv" 1. Sijhawm" thiab nias" Nkag" khawm, nws yuav nkag mus rau hauv lub sijhawm teeb tsa hom;
Thawj kab ntawm lub vijtsam qhia tau qhov chaw nyob ntawm" 【Sijhawm】" hauv cov xwm txheej teeb tsa lub sijhawm.
Qhov thib ob kab ntawm cov khoom qhia tau pom lub sijhawm teeb tsa": teev: feeb: thib ob" ;, piv txwv li,
GG quot; 11: 16: 56" yog lub sijhawm tabtom teem sijhawm.
Nias" Nkag" khawm kom xaiv txhua qhov chaw naj npawb (teev / feeb / thib ob), raws li koj pom, hauv kev hloov kho lub xeev, thaj chaw uas raug xaiv yuav raug nyem.
Nias qhov tseem ceeb" +" ntxiv rau 1, thaum tus naj npawb nce mus txog qhov siab tshaj plaws, nws yuav rov qab los rau hauv
Yam tsawg kawg nkaus tus nqi;
Nias qhov tseem ceeb" -" kom txo qis 1, thaum tus naj npawb nce mus txog tsawg kawg, nws yuav rov qab mus rau qhov siab tshaj plaws
tus nqi.
Nias" Ntawv qhia" khawm kom txuag thiab rov qab los rau ntawm lub tshuab raj teeb tsa.
Chaw teeb tsa cov qauv qhia raws li pom hauv daim duab 6:
【 | T | i | m | e | 】 | ||
1 | 1 | ： | 1 | 6 | ： | 5 | 6 |
Daim duab 6
II. Hauv cov xwm txheej ntawm kev teeb tsa cov ntawv qhia zaub mov, xaiv" 2.Qhov" thiab nias" Nkag" khawm, nws yuav nkag mus rau hom kev teeb tsa hnub tim;
Thawj kab ntawm lub vijtsam qhia tau qhov chaw nyob ntawm" 【Sijhawm】" nyob rau hnub tim qhov xwm txheej.
Qhov thib ob kab ntawm cov zaub qhia tau hais tias lub sijhawm tau teev" xyoo - lub hli - hnub" , piv txwv li" 13-01-01" yog
Lub sijhawm teeb tsa tam sim no.
Nias" Nkag" khawm kom xaiv txhua qhov chaw naj npawb (xyoo / hli / hnub), raws li koj pom, hauv kev hloov kho lub xeev, thaj chaw uas raug xaiv yuav raug nyem.
Nias qhov tseem ceeb" +" ntxiv rau 1, thaum tus naj npawb nce mus txog qhov siab tshaj plaws, nws yuav rov qab los rau hauv
Yam tsawg kawg nkaus tus nqi;
Nias qhov tseem ceeb" -" kom txo qis 1, thaum tus naj npawb nce mus txog tsawg kawg, nws yuav rov qab mus rau qhov siab tshaj plaws
tus nqi.
Nias" Ntawv qhia" khawm kom txuag thiab rov qab los rau ntawm lub tshuab raj teeb tsa.
Chaw teeb tsa cov qauv qhia raws li pom hauv daim duab 7:
【 | D | a | t | e | 】 | ||
1 | 3 | - | 0 | 1 | - | 0 | 1 |
Daim duab 7
III. Hauv cov xwm txheej ntawm kev teeb tsa cov ntawv qhia zaub mov, xaiv" 3 .Qhov" thiab nias" Nkag" khawm, nws yuav nkag mus rau suab tsim hom;
Thawj kab ntawm lub vijtsam qhia tau qhov chaw nyob ntawm" 【suab】" nyob rau hauv cov suab qhov xwm txheej.
Qhov thib ob kab ntawm cov zaub qhia tau" OPEN" lossis" KAW" uas txhais tau qhov xwm txheej ntawm lub suab
kev teeb tsa.
Nias qhov tseem ceeb" +" lossis" -" hloov suab kaw lossis qhib;
Nias" Ntawv qhia" khawm rov qab mus rau qhov chaw ntawv qhia zaub mov.
Suab Chaw yog li hauv daim duab 8:
【 | S | o | u | n | d | 】 |
O | P | E | N |
Daim duab 8
⑤ Hauv cov xwm txheej ntawm cov ntawv qhia zaub mov tseem ceeb, xaiv" 3. Qib" thiab nias" Nkag" khawm, nws yuav nkag mus rau hauv cov ntawv qhia zaub mov dhia;
Thawj kab ntawm lub vijtsam qhia tau qhov chaw nyob ntawm" 【Khiav】" hauv phiaj xwm kev zaub mov.
Qhov thib ob kab ntawm cov zaub qhia tau" Pib" lossis" Nres" uas txhais tau tias yog on / off qhov teeb meem ntawm lub
maub los.
Nias qhov tseem ceeb" +" lossis" -" rov qab pib los yog kaw.
Nias" Nkag" khawm rau txim tuag neeg siv' s kev xaiv; thiab nias" Ntawv qhia" khawm rov qab mus rau lub ntsiab
Ntawv qhia zaub mov.
Khiav ntawv qhia zaub mov raws li muaj nyob hauv daim duab 9:
【 | R | u | n | 】 |
S | t | a | r | t |
Daim duab 9
Sab nraud dimension
Kev sib tham ua
Cov tswv yim interface:
Nws yog lub pob rov pib dua, thaum tus maub los sib tsoo, tuaj yeem kov tus yuam sij no los teeb tsa.
Nws yog USB teeb liab sib koom ua ke nkag, thaum tshuab epistatic tom qab kho, tuaj yeem dhau los ntawm USB kab los rub tawm rau tus tswj.
Nws yog DC ntsaws, thaum lub zog ntsaws me me, tuaj yeem xaiv qhov chaw nres nkoj no rau input voltage.
Rau cov zis interface:
Nws yog load load 5 channel sab tsis zoo ncej;
Nws yog cov thauj khoom xaib 4 channel tsis zoo ncej;
Nws yog load load peb channel channel tsis zoo ncej;
Nws yog load load thib ob channel tsis zoo ncej;
Nws yog cov load load thawj channel tsis zoo ncej;
IsNws yog load load ntau hom anode;
⑦. Nws yog lub hwj huam muab cov tswv yim thiab cov ncej tsis zoo, thaum lub zog thauj khoom loj dhau, koj tuaj yeem xaiv 2 lub chaw nres nkoj no. (Ceeb toom: koj tsuas yog xav tau xaiv ib qho ntawm lub hwj chim xa hluav taws xob chaw nres nkoj thiab no 2 chaw nres nkoj)
Daim ntawv thov raug
